Triple-powered performance, urban edge
CLASS-LEADING PERFORMANCE
MUSCULAR STYLING
CONFIDENCE-INSPIRING CHASSIS
RIDER-FOCUSED TECHNOLOGY
|
|
|
|
|
|
| Type | Liquid-cooled, inline 3-cylinder, 12 valve, DOHC |
|---|---|
| Capacity | 660 cc |
| Bore | 74 mm |
| Stroke | 51.1 mm mm |
| Compression | 12:1 |
| Max Power | 94 HP (95 PS) (70 kW) @ 11,250 rpm |
| Max Torque | 50.2 ft-lb (68 Nm) @ 8,250 rpm |
| System | Multipoint, sequential electronic fuel injection with electronic throttle control |
| Exhaust | Stainless steel 3 into 1 header system with low single sided stainless steel silencer |
| Final Drive | X-ring chain |
| Clutch | Wet, multi-plate, slip and assist |
| Gearbox | 6-speed |
| Frame | Tubular steel perimeter frame |
|---|---|
| Swingarm | Twin-sided, fabricated steel |
| Front Wheel | Cast aluminium alloy, 5 spoke, 17 x 3.5 in |
| Rear Wheel | Cast aluminium alloy 5 spoke, 17 x 5.5 in |
| Front Tire | 120/70 ZR 17 |
| Rear Tire | 180/55 ZR 17 |
| Front Suspension | Showa 41 mm upside-down separate function big piston (SFF-BP) forks, 120 mm wheel travel |
| Rear Suspension | Showa monoshock (RSU), with adjustable preload and rebound damping, 130mm Wheel travel |
| Front Brakes | Twin, 310 mm fixed discs, 2-piston sliding calipers, OCABS |
| Rear Brakes | Single, 255 mm disc, single-piston sliding caliper, OCABS |
| Instrument Display and Functions | LCD multi-function instruments with integrated colour TFT screen |
| Width | 815 mm |
|---|---|
| Height | 1088 mm |
| Seat Height | 810 mm |
| Wheelbase | 1402 mm |
| Rake | 24.5 ° |
| Trail | 108 mm |
| Fuel capacity | 14 l |
| Wet Weight | 108 mm |
| Fuel consumption | 4.9 l/100km |
| Co2 standard | EPA Procedure |
| Standard description | CO2 emissions and fuel consumption data are measured according to regulation 40 CFR Part 86 Subpart F. Figures for fuel consumption are derived from specific test conditions and are for comparative purposes only. They may not reflect real driving results. |
